Compliance certificates | RoHS |
Audible alarm(s) | Yes |
Output Power | 280 W |
Auto-restart | Yes |
Audible alarm modes | Low battery alarm, Overload alarm |
Surge energy rating | 320 J |
Noise level | 38 dB |
Input Frequency | 50/60 Hz |
Surge protection features | Network |
Waveform | Sine |
Hold time (min) | 4 ms |
Input operation voltage (max) | 302 V |
Hold time (max) | 8 ms |
Surge protection | Yes |
Input operation voltage (min) | 151 V |
Automatic Voltage Regulation (AVR) | Yes |
Output Power Capacity | 0.45 kVA |
UPS topology | Line-Interactive |
Certification | C-tick, CE, GOST, VDE, PEP, EOLI |
Product colour | Grey |
Rack capacity | 1U |
LED indicators | Battery replacement |
Form factor | Rackmount/Tower |
Storage temperature (T-T) | -15 - 45 °C |
Storage relative humidity (H-H) | 0 - 95% |
Non-operating altitude | 0 - 15000 m |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Depth | 383 mm |
Package height | 164 mm |
Height | 44 mm |
Package width | 476 mm |
Width | 432 mm |
Weight | 10.2 kg |
Rack mount kit | Yes |
CABLES INCLUDED | RS-232 |
Manual | Yes |
Serial interface | Yes |
Serial ports quantity | 1 |
Power plug | C14 coupler |
AC outlets quantity | 4 AC outlet(s) |
Number of output IEC jumpers | 2 |
Serial interface type | RS-232 |
AC outlet types | C13 coupler |
Battery Recharge Time | 5 h |
Typical backup time at full load | 5.9 min |
Automatic battery test | Yes |
Battery capacity | 108 VAh |
Hot-swap battery | Yes |
Typical backup time at half load | 19.4 min |
Battery life (max) | 5 year(s) |
Battery Technology | Sealed Lead Acid (VRLA) |
Nominal Output Voltage | 230 V |
Harmonized System (HS) code | 85078000 |
