features | |
USV-Topology | Line-Interaktiv |
output capacity | 1,2 kVA |
output power | 720 W |
waveform | Sine |
Input operating voltage (min) | 165 V |
Input operating voltage (max) | 290 V |
input frequency | 50/60 Hz |
Output operating voltage (min) | 220 V |
Output operating voltage (max) | 240 V |
output frequency | 50/60 Hz |
Eigenschaft | Nachhaltigkeitskonformität |
Anstieg der Energiemenge | 150 J |
reaction time | 4 ms |
heat dissipation | 137 BTU/h |
Surge Protection Features | Faxen, Modem, Netzwerk, Telefon |
energy conservation properties | Kurzschluß |
Audible alarm modes | Alarm bei Batteriebetrieb, Störung, Warnung bei geringer Batterie, Überlastungsalarm |
connections and interfaces | |
AC plug types | Typ F |
Number of AC outlets | 8 AC-Ausgänge |
Number of USB 2.0 ports | 1 |
USB-Port-Typ | USB Typ-A |
Modem (RJ-11) Port | 2 |
Number of Ethernet LAN ports (RJ-45) | 2 |
battery | |
Rechargeable battery technology | Plombierte Bleisäure (VRLA) |
battery voltage | 230 V |
Number of rechargeable batteries/batteries supported | 2 |
Typical backup time at full load | 2 min |
Typical backup time at half load | 9 min |
battery charge time | 8 h |
Battery cartridge change | RBP0063 |
Design | |
form factor | Desktop |
housing material | Kunststoff |
cable length | 1,5 m |
Product color | Schwarz |
Display-Typ | LCD |
LED indicators | Akkustand, Leistung, Status |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -20 - 50 °C |
Operating relative humidity | 0 - 90% |
humidity during storage | 0 - 90% |
operating height | 0 - 3000 m |
storage height | 0 - 3000 m |
certificates | |
Konformitätsbescheinigungen | CE, EAC, RoHS |
sustainability | |
weight and dimensions | |
broad | 166 mm |
depth | 288 mm |
height | 118 mm |
Weight | 8,2 kg |
package weight | 8,43 kg |
logistic data | |
Goods tariff number (HS) | 8504408590 |
Other functions | |
Anzahl der Phasen | 1 |
