Surge protection features | Network |
Input operation voltage (min) | 170 V |
Maximum current | 10 A |
Output voltage Total Harmonic Distortion (THD) | 10% |
Surge energy rating | 405 J |
Response time | 4 ms |
Power protection features | Short circuit |
UPS topology | Standby (Offline) |
Input operation voltage (max) | 270 V |
Input Frequency | 50/60 Hz |
Output frequency | 50/60 Hz |
Output Power Capacity | 0.9 kVA |
Waveform | Pure sine |
EMI/RFI noise filtering | Yes |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
Auto-restart | Yes |
Output Power | 540 W |
Audible alarm(s) | Yes |
Surge protection | Yes |
Certification | CE, EAC, RCM |
Product colour | Black |
LED indicators | Operation |
Cable length | 1.83 m |
Display type | LCD |
Form factor | Tower |
Housing material | Plastic |
Operating altitude | 0 - 3000 m |
Storage relative humidity (H-H) | 0 - 95% |
Operating relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | 15 - 45 °C |
Non-operating altitude | 0 - 15000 m |
Operating temperature (T-T) | 32 - 104 °F |
Height | 275 mm |
Depth | 230 mm |
Package height | 335 mm |
Package width | 195 mm |
Width | 100 mm |
Weight | 6.6 kg |
USB 2.0 ports quantity | 1 |
AC outlets quantity | 6 AC outlet(s) |
Power plug | C14 coupler |
Ethernet LAN (RJ-45) ports | 1 |
Modem (RJ-11) ports | 1 |
Battery voltage | 230 V |
Typical backup time at full load | 1 min |
Number of batteries supported | 1 |
Typical backup time at half load | 7 min |
Battery Technology | Sealed Lead Acid (VRLA) |
Battery Recharge Time | 8 h |
Compatible operating systems | Windows 7/Vista/XP/2000/Server 2003, Linux |
Nominal Output Voltage | 230 V |
Nominal input voltage | 165-265 V |
Interface | USB |
Harmonized System (HS) code | 8504408590 |
