features | |
USV-Topology | Line-Interaktiv |
output capacity | 1 kVA |
output power | 900 W |
waveform | Reiner Sinus |
Input operating voltage (min) | 151 V |
Input operating voltage (max) | 301 V |
input frequency | 50/60 Hz |
Output operating voltage (min) | 230 V |
Output operating voltage (max) | 230 V |
output frequency | 50/60 Hz |
Eigenschaft | Überlastung Schutz |
Anstieg der Energiemenge | 405 J |
reaction time | 4 ms |
power factor | 0,9 |
energy conservation properties | Überlastschutz |
connections and interfaces | |
AC plug types | C13-Koppler |
plug | C14-Koppler |
Number of AC outlets | 8 AC-Ausgänge |
Number of output IEC jumpers | 1 |
Number of USB 2.0 ports | 1 |
Number of serial ports | 1 |
battery | |
Rechargeable battery technology | Plombierte Bleisäure (VRLA) |
Number of rechargeable batteries/batteries supported | 1 |
Typical backup time at full load | 4 min |
Typical backup time at half load | 16 min |
battery charge time | 8 h |
Design | |
form factor | Tower |
housing material | Metall |
Product color | Schwarz |
Display-Typ | LCD |
LED indicators | Fehler, Tätigkeit |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -15 - 45 °C |
Operating relative humidity | 0 - 95% |
humidity during storage | 0 - 95% |
operating height | 0 - 3000 m |
storage height | 0 - 15000 m |
certificates | |
certification | CE, EAC, RCM, RoHS |
scope of delivery | |
Supplied cables | USB-Kabel |
weight and dimensions | |
broad | 170 mm |
depth | 432 mm |
height | 221 mm |
Weight | 18,9 kg |
package weight | 21,3 kg |
logistic data | |
Goods tariff number (HS) | 8504408590 |
Country of origin | China |
Other functions | |
Compatible operating systems | Windows 7 / Vista / XP / 2000, Server 2003 / 2008, Linux |
