Output frequency | 50/60 Hz |
Automatic Voltage Regulation (AVR) | Yes |
Waveform | Pure sine |
Audible alarm(s) | Yes |
Audible alarm modes | Overload alarm |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Input Frequency | 50/60 Hz |
Noise level | 52.5 dB |
EMI/RFI noise filtering | Yes |
Output Power Capacity | 1500 kVA |
Power protection features | Overload |
Input operation voltage (max) | 302 V |
Output power factor | 1 |
Surge protection | Yes |
Input operation voltage (min) | 151 V |
Maximum current | 10 A |
Output Power | 1500 W |
Emergency Power Off (EPO) | Yes |
UPS topology | Line-Interactive |
Power Factor Correction (PFC) type | Active |
Surge energy rating | 2430 J |
Certification | CE, FCC Class B, UL, RCM, VCCI |
Display | LCD |
Form factor | Rackmount/Tower |
Rack capacity | 2U |
Housing material | Metal |
LED indicators | Yes |
RoHS compliance | Y |
Product colour | Black |
Cable length | 3.05 m |
Operating temperature (T-T) | 0 - 40 °C |
Non-operating altitude | 0 - 15000 m |
Storage relative humidity (H-H) | 0 - 95% |
Operating relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Storage temperature (T-T) | -15 - 45 °C |
Weight | 29.4 kg |
Width | 433 mm |
Depth | 412 mm |
Height | 86.5 mm |
Package width | 560 mm |
Package height | 275 mm |
Rack mount kit | Yes |
Power plug | C14 coupler |
Serial interface | Yes |
Ethernet LAN (RJ-45) ports | 2 |
Serial ports quantity | 1 |
USB Port | Yes |
AC outlets quantity | 10 AC outlet(s) |
USB 2.0 ports quantity | 1 |
AC outlet types | C13 coupler |
Emergency Power Off (EPO) connector | Yes |
Serial interface type | RS-232 |
Number of batteries supported | 1 |
Battery Technology | Sealed Lead Acid (VRLA) |
Battery Recharge Time | 3 h |
Hot-swap battery | Yes |
