Warranty period | 3 year(s) |
Sustainability certificates | ENERGY STAR |
Sustainability compliance | Yes |
Compliance certificates | RoHS |
Response time | 4 ms |
Noise level | 57.5 dB |
Output Power | 3000 W |
Surge protection features | Network |
Power protection features | Overload |
Maximum current | 10 A |
Surge protection | Yes |
Power Factor Correction (PFC) type | Active |
Output Power Capacity | 3 kVA |
Audible alarm(s) | Yes |
Number of output phases | 1 |
UPS topology | Line-Interactive |
Power factor | 1 |
Output frequency | 50/60 Hz |
Automatic Voltage Regulation (AVR) | Yes |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
Output operation voltage (min) | 220 V |
Input Frequency | 50/60 Hz |
Input operation voltage (min) | 159 V |
Number of input phases | 1 |
Output operation voltage (max) | 240 V |
Emergency Power Off (EPO) | Yes |
Heat dissipation | 120.8 BTU/h |
Management protocols | SNMP/HTTP |
Surge energy rating | 2430 J |
EMI/RFI noise filtering | Yes |
Waveform | Pure sine |
Input operation voltage (max) | 288 V |
Rack capacity | 2U |
Cooling type | Active |
Form factor | Rackmount/Tower |
Cable length | 2.4 m |
LED indicators | Power |
Product colour | Black |
Control Type | Buttons |
Display type | LCD |
Built-in fan | Yes |
Housing material | Metal |
Operating relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating altitude | 0 - 3000 m |
Storage relative humidity (H-H) | 0 - 95% |
Non-operating altitude | 0 - 15000 m |
Weight | 32.3 kg |
Package height | 275 mm |
Package width | 560 mm |
Height | 86.5 mm |
Depth | 500 mm |
Width | 433 mm |
CABLES INCLUDED | Serial, USB cable |
Manual | Yes |
Rack mount kit | Yes |
Ethernet LAN (RJ-45) ports | 2 |
AC outlets quantity | 8 AC outlet(s) |
Emergency Power Off (EPO) connector | Yes |
Serial interface type | RS-232 |
AC outlet types | C13 coupler |
USB Port | Yes |
Serial ports quantity | 1 |
Power plug | C20 coupler |
RS-232 ports | 1 |
Serial interface | Yes |
Number of batteries supported | 1 |
Typical backup time at full load | 1.3 min |
Typical backup time at half load | 6.4 min |
Hot-swap battery | Yes |
Battery Recharge Time | 3 h |
Battery Technology | Sealed Lead Acid (VRLA) |
Battery type | RBP0129 |
Harmonized System (HS) code | 8504408590 |
