features | |
USV-Topology | Line-Interaktiv |
output capacity | 0,6 kVA |
output power | 600 W |
waveform | Pseudo sine |
Input operating voltage (min) | 162 V |
Input operating voltage (max) | 290 V |
input frequency | 50 Hz |
output frequency | 50 Hz |
Regulation of the output voltage | 10% |
Eigenschaft | LED-Anzeigen |
Transmission time (line mode to battery mode) | 2 ms |
Number of input phases | 1 |
Number of output phases | 1 |
power factor | 0,6 |
noise level | 40 dB |
Surge Protection Features | Digital Subscriber Line (DSL), Modem, Netzwerk |
energy conservation properties | Batterieentladung, Überlast, Überlastschutz |
Audible alarm modes | Alarm bei Batteriebetrieb, Störung, Warnung bei geringer Batterie, Überlastungsalarm |
connections and interfaces | |
plug | Typ F |
Number of AC outlets | 4 AC-Ausgänge |
Number of USB 2.0 ports | 1 |
USB-Port-Typ | USB Typ-B |
Serial interface | RS-232 |
Number of serial ports | 1 |
RS-232 port | 1 |
Number of Ethernet LAN ports (RJ-45) | 2 |
battery | |
battery capacity | 7 Ah |
battery voltage | 12 V |
Number of rechargeable batteries/batteries supported | 2 |
Akku-Ladezeit (90 %) | 6 h |
Design | |
form factor | Tower |
Product color | Schwarz |
Display-Typ | LCD |
operating conditions | |
operating temperatur | 0 - 40 °C |
Operating relative humidity | 0 - 95% |
weight and dimensions | |
broad | 150 mm |
depth | 338 mm |
height | 162 mm |
Weight | 7,8 kg |
package weight | 8,1 kg |
packaging volume | 18273,6 cm³ |
logistic data | |
UK Customs Tariff Code | 85044085 |
Goods tariff number (HS) | 85078000 |
Country of origin | China |
Other functions | |
output connections | 4 x CEE 7/7 |
Nominal output voltage | 230 V |
Nominal input voltage | 230 V |
