Total Harmonic Distortion (THD) (linear load) | 3% |
Output voltage regulation | 1% |
Waveform | Sine |
Output frequency | 47/63 Hz |
Total Harmonic Distortion (THD) (non-linear load) | 6% |
Crest factor | 3:1 |
Output Power Capacity | 1 kVA |
Output Power | 900 W |
Input operation voltage (max) | 300 V |
Power factor | 0.99 |
Audible alarm(s) | Yes |
Output operation voltage (max) | 240 V |
UPS topology | Double-conversion (Online) |
Input operation voltage (min) | 120 V |
Input Frequency | 40 - 70 Hz |
Output operation voltage (min) | 200 V |
Noise level | 50 dB |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
Control Type | Buttons |
Display type | LCD |
LED indicators | Yes |
Product colour | Black |
Form factor | Tower |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 20 - 90% |
Weight | 9.8 kg |
Depth | 282 mm |
Width | 145 mm |
Height | 220 mm |
CABLES INCLUDED | Input power cable, USB cable |
Manual | Yes |
Batteries Included | Yes |
USB port type | USB Type-B |
Serial interface | Yes |
USB 2.0 ports quantity | 1 |
Serial interface type | RS-232 |
RS-232 ports | 1 |
Number of output IEC jumpers | 3 |
USB Port | Yes |
Battery recharge time (90%) | 4 h |
Battery voltage | 12 V |
Battery capacity | 9 Ah |
Typical backup time at full load | 3.2 min |
Typical backup time at half load | 8.9 min |
Number of battery cells | 2 |
Number of phases | 1 |
Harmonized System (HS) code | 85078000 |
