Input Frequency | 40 - 70 Hz |
Noise level | 50 dB |
Output Power Capacity | 3 kVA |
Input operation voltage (min) | 120 V |
Power factor | 0.99 |
Output Power | 2700 W |
Audible alarm(s) | Yes |
Total Harmonic Distortion (THD) (non-linear load) | 6% |
UPS topology | Double-conversion (Online) |
Total Harmonic Distortion (THD) (linear load) | 3% |
Output voltage regulation | 1% |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
Waveform | Sine |
Output frequency | 47/63 Hz |
Crest factor | 3:1 |
Input operation voltage (max) | 300 V |
Output operation voltage (min) | 200 V |
Output operation voltage (max) | 240 V |
Display type | LCD |
LED indicators | Yes |
Product colour | Black |
Form factor | Tower |
Control Type | Buttons |
Operating relative humidity (H-H) | 20 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Height | 318 mm |
Width | 190 mm |
Depth | 421 mm |
Weight | 27.6 kg |
Manual | Yes |
CABLES INCLUDED | Input power cable, USB cable |
Batteries Included | Yes |
RS-232 ports | 1 |
USB Port | Yes |
USB 2.0 ports quantity | 1 |
Serial interface type | RS-232 |
Number of output IEC jumpers | 4 |
USB port type | USB Type-B |
Serial interface | Yes |
Battery voltage | 12 V |
Typical backup time at half load | 9.8 min |
Typical backup time at full load | 3.5 min |
Battery capacity | 9 Ah |
Number of battery cells | 6 |
Battery recharge time (90%) | 4 h |
Harmonized System (HS) code | 85078000 |
