features | |
USV-Topology | Standby (Offline) |
output capacity | 0,6 kVA |
output power | 360 W |
waveform | Sine |
Input operating voltage (min) | 220 V |
Input operating voltage (max) | 240 V |
input frequency | 50/60 Hz |
Output operating voltage (min) | 220 V |
Output operating voltage (max) | 240 V |
output frequency | 50/60 Hz |
Regulation of the output frequency | ±1 Hz |
Regulation of the output voltage | ±10%% |
reaction time | 6 ms |
noise level | 40 dB |
energy conservation properties | Überlast, Tiefentladeabschaltung, Überlastschutz |
connections and interfaces | |
Number of AC outlets | 6 AC-Ausgänge |
Eigenschaft | Kaltstart |
Number of USB 2.0 ports | 2 |
USB-Port-Typ | USB Typ-A |
Number of Ethernet LAN ports (RJ-45) | 2 |
battery | |
battery capacity | 4,5 Ah |
battery voltage | 12 V |
Number of rechargeable batteries/batteries supported | 1 |
Typical backup time at full load | 13 min |
battery charge time | 8 h |
Design | |
form factor | Kompakt |
Product color | Schwarz |
Display-Typ | LCD |
safety | CE |
operating conditions | |
operating temperatur | 0 - 40 °C |
Operating relative humidity | 0 - 90% |
weight and dimensions | |
broad | 158,5 mm |
depth | 305 mm |
height | 95 mm |
Weight | 2,6 kg |
logistic data | |
Goods tariff number (HS) | 85078000 |
