Power factor | 0.8 |
Input Frequency | 40/70 Hz |
Maximum current | 10 A |
Noise level | 50 dB |
Response time | 4 ms |
Input operation voltage (min) | 100 V |
Audible alarm(s) | Yes |
Efficiency | 88% |
Output Power Capacity | 1 kVA |
Output operation voltage (min) | 100 V |
Input operation voltage (max) | 240 V |
Audible alarm modes | Alarm when on battery, Fault, Overload alarm, Low battery alarm |
Number of input phases | 1 |
Output operation voltage (max) | 240 V |
Input power factor | 0.99 |
ECO fashion | Yes |
Output voltage regulation | -1 - 1% |
Waveform | Pure sine |
Output frequency | 47/63 Hz |
Output voltage Total Harmonic Distortion (THD) | 6% |
Number of output phases | 1 |
UPS topology | Double-conversion (Online) |
Crest factor | 3:1 |
Product colour | Black |
Form factor | Tower |
Display type | LED |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 20 - 90% |
Width | 145 mm |
Weight | 8.6 kg |
Height | 282 mm |
Depth | 220 mm |
PACKAGE WEIGHT | 10.1 kg |
CABLES INCLUDED | Output power cable, RS-232, Input power cable |
Manual | Yes |
Certification | CE |
Compliance certificates | RoHS |
Serial ports quantity | 1 |
AC outlets quantity | 3 AC outlet(s) |
AC outlet types | C13 coupler |
Serial interface | Yes |
Serial interface type | RS-232 |
Cold start | Yes |
Typical backup time at half load | 9 min |
Typical backup time at full load | 30 min |
Battery voltage | 12 V |
Battery Recharge Time | 4 h |
Battery Technology | Sealed Lead Acid (VRLA) |
Battery capacity | 9 Ah |
Charging current | 1 A |
