UPS topology | Standby (Offline) |
Output voltage regulation | 20% |
Efficiency | 95% |
Input operation voltage (min) | 170 V |
Input operation voltage (max) | 280 V |
Output operation voltage (min) | 220 V |
Input Frequency | 50/60 Hz |
Waveform | Sine |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
Output Power Capacity | 0.6 kVA |
Output frequency regulation | 2 Hz |
Output Power | 300 W |
Audible alarm(s) | Yes |
Output power factor | 0.5 |
Output operation voltage (max) | 240 V |
LED indicators | Yes |
Operating relative humidity (H-H) | 0 - 85% |
Operating temperature (T-T) | 0 - 40 °C |
Depth | 320 mm |
Width | 125 mm |
Weight | 2.8 kg |
Height | 86 mm |
Package width | 378 mm |
Manual | Yes |
Package height | 90 mm |
AC outlet types | Type E |
AC outlets quantity | 6 AC outlet(s) |
Ethernet LAN (RJ-45) ports | 2 |
Typical backup time at full load | 2 min |
Battery recharge time (90%) | 10 h |
Number of batteries supported | 1 |
Battery voltage | 12 V |
Typical backup time at half load | 8 min |
Battery capacity | 5 Ah |
