Waveform | Sine |
Efficiency | 89% |
Output voltage Total Harmonic Distortion (THD) | 1% |
UPS topology | Double-conversion (Online) |
ECO fashion | Yes |
Output power factor | 1 |
Input current Total Harmonic Distortion (THD) | 5% |
Output operation voltage (max) | 240 V |
Output Power Capacity | 1.5 kVA |
Output voltage regulation | 1% |
Crest factor | 3:1 |
Input operation voltage (max) | 300 V |
Output operation voltage (min) | 200 V |
Noise level | 45 dB |
Input operation voltage (min) | 110 V |
Emergency Power Off (EPO) | Yes |
Response time | 0 ms |
Output Power | 1500 W |
Input Frequency | 40/70 Hz |
Form factor | Rackmount/Tower |
LED indicators | Yes |
Display type | LCD |
Operating temperature (T-T) | 0 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Weight | 15.8 kg |
Width | 438 mm |
Depth | 445 mm |
Height | 85.5 mm |
Package height | 240 mm |
Package depth | 587 mm |
Package width | 498 mm |
PACKAGE WEIGHT | 19 kg |
Manual | Yes |
CABLES INCLUDED | Input power cable, Output power cable, USB cable |
AC outlet types | C13 coupler |
Serial interface type | RS-232 |
Emergency Power Off (EPO) connector | Yes |
Serial interface | Yes |
Serial ports quantity | 1 |
USB 2.0 ports quantity | 1 |
Power plug | C14 coupler |
AC outlets quantity | 8 AC outlet(s) |
USB Port | Yes |
Charging current | 1.5 A |
Battery Recharge Time | 3 h |
Hot-swap battery | Yes |
Battery capacity | 9 Ah |
Battery voltage | 12 V |
Number of batteries supported | 3 |
Harmonized System (HS) code | 85078000 |
Warnings | Do not disassemble the unit housing, there may be a risk of electric shock. |
