Noise level | 50 dB |
Output Power | 3000 W |
Power protection features | Overload |
Crest factor | 3:1 |
UPS topology | Double-conversion (Online) |
Output Power Capacity | 3 kVA |
Output voltage regulation | 1% |
Input operation voltage (max) | 300 V |
Efficiency (On-line mode) | 93% |
Input operation voltage (min) | 160 V |
Output operation voltage (max) | 240 V |
Output power factor | 1 |
Emergency Power Off (EPO) | Yes |
Waveform | Pure sine |
Output operation voltage (min) | 200 V |
Input Frequency | 40/70 Hz |
ECO fashion | Yes |
Cooling type | Active |
Form factor | Rackmount/Tower |
LED indicators | Yes |
Product colour | Black |
Rack capacity | 2U |
Built-in fan | Yes |
Display type | LCD |
Operating temperature (T-T) | 0 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Package width | 580 mm |
Width | 438 mm |
Depth | 600 mm |
Height | 85.5 mm |
Weight | 26.2 kg |
Package height | 240 mm |
CABLES INCLUDED | Input power cable, Output power cable, USB cable |
Manual | Yes |
Rack mount kit | Yes |
RS-232 ports | 1 |
Power plug | C20 coupler |
AC outlets quantity | 9 AC outlet(s) |
AC outlet types | C13 coupler |
Serial interface | Yes |
USB Port | Yes |
Emergency Power Off (EPO) connector | Yes |
USB port type | USB Type-B |
Serial interface type | RS-232 |
Number of batteries supported | 6 |
Battery capacity | 9 Ah |
Battery voltage | 12 V |
Charging current | 1.5 A |
Battery Recharge Time | 3 h |
