Output frequency regulation | 0.5 Hz |
Input Frequency | 45/55 Hz |
Input operation voltage (max) | 290 V |
Output operation voltage (max) | 230 V |
Output voltage regulation | 10% |
Power protection features | Overload |
Output Power | 300 W |
UPS topology | Line-Interactive |
Waveform | Sine |
Output Power Capacity | 0.5 kVA |
Output power factor | 0.6 |
Output operation voltage (min) | 230 V |
Input operation voltage (min) | 165 V |
Rack capacity | 1U |
Display type | LCD |
Form factor | Rackmount |
Product colour | Black |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 0 - 95% |
Height | 44 mm |
Package height | 150 mm |
Width | 433 mm |
Depth | 216 mm |
Package width | 537 mm |
Weight | 7.6 kg |
CABLES INCLUDED | USB cable |
Manual | Yes |
USB Port | Yes |
AC outlets quantity | 4 AC outlet(s) |
AC outlet types | C13 coupler |
Emergency Power Off (EPO) connector | Yes |
RS-232 ports | 1 |
Typical backup time at full load | 0.8 min |
Number of batteries supported | 2 |
Battery capacity | 7 Ah |
Typical backup time at half load | 10.3 min |
Battery voltage | 6 V |
Battery Recharge Time | 8 h |
Harmonized System (HS) code | 85078000 |
