| connections and interfaces | |
| transmission technology | Kabelgebunden |
| host interface | PCI Express |
| interface | PCIe v2.1 (5.0 GT/s) |
| Number of Ethernet LAN ports (RJ-45) | 4 |
| PCI version | 2.1 |
| PCI-Karten-Formfaktor | Volle Höhe (Niedriges Profil) |
| network | |
| Maximum data transfer rate | 1000 Mbit/s |
| mesh standard | IEEE 802.1as, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Eigenschaft | Intel® Connectivity-Virtualisierungstechnik (VT-c) |
| Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
| wiring technology | 10/100/1000BaseT(X) |
| Supported network protocols | TCP, UDP, IP |
| Maximum working distance | 100 m |
| LAN-Controller | Intel® I350 |
| Design | |
| component for | Server |
| chipset | Intel® I350 |
| energy | |
| Power consumption (standard operation) | 5 W |
| system requirement | |
| Compatible operating systems | https://www.intel.com/content/www/us/en/support/articles/000025890/network-and-i-o/ethernet-products.html |
| operating conditions | |
| operating temperatur | 0 - 55 °C |
| Storage temperature range | -40 - 70 °C |
| humidity during storage | 35 - 90% |
| weight and dimensions | |
| broad | 68,9 mm |
| depth | 135,4 mm |
| logistic data | |
| Goods tariff number (HS) | 85176990 |
| Other functions | |
| cable type | Cat 5 up to 100m |
| market segment | Server |
| Geschwindigkeits & Slot Weite | 5.0 GT/s, x4 Lane |
| product type | Network Interface Card |
| Thermal Design Power (TDP) | 5 W |
| processor family | Gigabit Ethernet Adapters (up to 2.5GbE)-Gigabit Ethernet Adapters (up to 2.5GbE) |
| Start date | Q3'14 |
| Netzwerk-Schnittstelle-Karte Kabelmedium | Copper |
| Netzwerkschnittstelle Kartentyp | Server |
| URL Produktbeschreibung | http://www.intel.com/content/www/us/en/ethernet-controllers/ethernet-i350-server-adapter-brief.html?wapkw=i350 |
| Status | Launched |
| Last change | 63903513 |
| Ethernet-Adapter ARK ID | 84805 |
| Speicher über Ethernet | iSCSI, NFS |
| Export Control Classification Number (ECCN) | 5A991 |
| Commodity Classification System for Automated Tracking (CCATS) | NA |
| controller type | Intel I350 |
| height of the bracket | Low-Profile (LP) / Full-Height (FH) |
| product family | Intel Gigabit server adapter |
| product line | Intel® I350 |
| product code name | Powerville |
