connections and interfaces | |
transmission technology | Kabelgebunden |
host interface | PCI Express |
interface | Faser |
Number of fiber connectors | 1 |
Optical cable connector | QSFP28 |
PCI version | 4.0 |
network | |
Maximum data transfer rate | 100000 Mbit/s |
Ethernet LAN data transfer rates | 1000,10000,25000,50000,100000 Mbit/s |
LAN-Controller | Intel E810 |
Design | |
component for | Server |
Eigenschaft | Intel® Connectivity-Virtualisierungstechnik (VT-c) |
system requirement | |
Compatible operating systems | https://www.intel.com/content/www/us/en/support/articles/000025890/ethernet-products.html |
operating conditions | |
operating temperatur | 0 - 60 °C |
Storage temperature range | -40 - 70 °C |
logistic data | |
Goods tariff number (HS) | 85176990 |
Other functions | |
cable type | QSFP28 port - DAC, Optics, and AOC's |
Geschwindigkeits & Slot Weite | 16.0 GT/s, x16 Lane |
Speicher über Ethernet | iSCSI, NFS |
Start date | Q4'20 |
Netzwerkschnittstelle Kartentyp | Server |
Status | Launched |
processor family | 800 Network Adapters (up to 100GbE)-800 Network Adapters (up to 100GbE) |
Export Control Classification Number (ECCN) | 5A991 |
Commodity Classification System for Automated Tracking (CCATS) | NA |
height of the bracket | Low-Profile (LP) / Full-Height (FH) |
product line | 800 Series Network Adapters (up to 100GbE) |
