connections and interfaces | |
transmission technology | Kabelgebunden |
host interface | PCI Express |
interface | Faser |
Number of fiber connectors | 2 |
Optical cable connector | QSFP28 |
PCI version | 4.0 |
PCI-Karten-Formfaktor | Volle Höhe |
network | |
Maximum data transfer rate | 200000 Mbit/s |
mesh standard | IEEE 1588 |
LAN-Controller | Intel E810 |
Design | |
component for | Server |
Product color | Grün, Grau |
Eigenschaft | Intel® Connectivity-Virtualisierungstechnik (VT-c) |
certification | FCC B, UL, CE, VCCI, BSMI, RCM, KCC |
energy | |
Power consumption (standard operation) | 21,8 W |
operating conditions | |
operating temperatur | 0 - 60 °C |
Storage temperature range | -40 - 70 °C |
weight and dimensions | |
broad | 167 mm |
depth | 111 mm |
Technical details | |
Konformitätsbescheinigungen | RoHS |
logistic data | |
Goods tariff number (HS) | 8517620090 |
Other functions | |
Geschwindigkeits & Slot Weite | 16.0 GT/s, x16 Lane |
Speicher über Ethernet | iSCSI, NFS |
Export Control Classification Number (ECCN) | 5A991 |
