connections and interfaces | |
transmission technology | Kabellos |
host interface | M.2 |
interface | WLAN / Bluetooth |
network | |
Maximum data transfer rate | 5000 Mbit/s |
Eigenschaft | Under vPro unterstützt |
WiFi band | Tri-Band (2,4 GHz / 5 GHz / 5 GHz) |
Top WLAN-Standard | Wi-Fi 7 (802.11be) |
WLAN-Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
Supported security algorithms | 128-bit AES, 256-bit AES, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, WPA2, WPA3 |
Bluetooth-Version | 5.4 |
Design | |
component for | PC/Laptop |
antenna type | 2x2 |
form factor | M.2 2230 |
system requirement | |
Supports Windows operating systems | Windows 10, Windows 11 |
operating conditions | |
operating temperatur | 0 - 50 °C |
Operating relative humidity | 50 - 90% |
weight and dimensions | |
broad | 22 mm |
depth | 30 mm |
height | 2,42 mm |
Weight | 3,06 g |
Technical details | |
Konformitätsbescheinigungen | CB, UL |
logistic data | |
Goods tariff number (HS) | 8517620090 |
Other functions | |
Status | Launched |
Ethernet-Adapter ARK ID | 230079 |
Export Control Classification Number (ECCN) | 5A991B |
