connections and interfaces | |
transmission technology | Kabellos |
host interface | M.2 |
interface | Wi-Fi(PCIe), BT(USB) |
network | |
Maximum data transfer rate | 1730 Mbit/s |
Eigenschaft | Under vPro unterstützt |
WiFi band | Dual-Band (2,4 GHz/5 GHz) |
Top WLAN-Standard | Wi-Fi 5 (802.11ac) |
WLAN-Standards | Wi-Fi 5 (802.11ac) |
Data transfer speed WiFi | 1734 Mbit/s |
Supported security algorithms | EAP-AKA, EAP-SIM, EAP-TLS, PEAP, TTLS, WPA, WPA2, WPA2-PSK |
bandwidth (first) | 2,4 GHz |
bandwidth (second) | 5 GHz |
Bluetooth-Version | 5 |
Design | |
The Antenna Design | Intern |
antenna type | 2x2 |
form factor | M.2 2230, M.2 1216 |
safety | UL, C-UL, CB |
certification | Wi-Fi, FIPS, FISMA |
system requirement | |
Compatible operating systems | Windows 10, 64-bit*|Linux* |
Support for other operating systems | ChromeOS |
operating conditions | |
operating temperatur | 0 - 80 °C |
Operating relative humidity | 50 - 90% |
weight and dimensions | |
broad | 30 mm |
depth | 2,4 mm |
height | 22 mm |
Weight | 2,9 g |
logistic data | |
Goods tariff number (HS) | 8517620090 |
Other functions | |
number of antennas | 4 |
Minimum operating temperature | 0 °C |
Maximum operating temperature | 80 °C |
Start date | Q4'17 |
URL Produktbeschreibung | https://www.intel.com/content/www/us/en/wireless-products/dual-band-wireless-ac-9260-brief.html |
product type | Wireless |
Status | Launched |
processor family | Intel Wireless-AC Products |
Ethernet-Adapter ARK ID | 99445 |
Export Control Classification Number (ECCN) | 5A992CN3 |
Commodity Classification System for Automated Tracking (CCATS) | G165483 |
Zustimmung | FIPS, FISMA |
product line | Intel® Wireless Products |
product code name | Thunder Peak |
