processor | |
processor manufacturer | Intel |
processor socket | LGA 1851 (Socket V1) |
Compatible processors | Intel Core Ultra (Series 2) |
Supported processor slots | LGA 1851 |
Storage | |
Supported memory | DDR5-SDRAM |
Number of memory slots | 4 |
memory type | DIMM |
memory voltage | 1.1 V |
ECC-Kompatibilität | ECC & Nicht-ECC |
Supported memory clock speed (max.) | 5600 MHz |
RAM memory maximum | 192 GB |
Supported memory module capacities | 16GB, 24GB, 32GB, 8GB, 48GB |
Eigenschaft | Ethernet/LAN |
storage controller | |
Supported storage drives | HDD & SSD |
Supported storage drive interfaces | M.2, SATA III |
Maximum supported number of HDD | 8 |
Number of supported storage drives | 10 |
RAID Level | 0, 1, 5, 10 |
Internal I/O ports | |
USB 3.2 Gen 1 (3.1 Gen 1) ports | 2 |
USB 3.2 Gen 2x2-Anschlüsse | 1 |
SATA III connectors | 8 |
Number of chassis fan plugs | 7 |
Number of COM connectors | 1 |
I/O ports on the back | |
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports | 3 |
USB 3.2 Gen 2x2 Type-C number of ports | 1 |
Number of Ethernet LAN ports (RJ-45) | 2 |
Number of HDMI ports | 1 |
Number of DisplayPort connections | 1 |
Quantity of Thunderbolt ports | 1 |
network | |
Ethernet interfaces type | 2.5 Gigabit Ethernet, Gigabit Ethernet |
features | |
audio chip | ALC 888S |
component for | Server |
Motherboardformfaktor | ATX |
Motherboard chipset family | Intel |
expansion slots | |
PCI Express x4 slots (Gen 4.x) | 1 |
PCI Express x16 slots (Gen 5.x) | 2 |
Number of M.2 (M) slots | 2 |
1. M.2 größte Schlüsselgröße | 2280 |
1. M.2 höchste PCI Express-Generation | 5.0 |
2. M.2 größte Schlüsselgröße | 22110 |
2. M.2 höchste PCI Express-Generation | 4.0 |
BIOS | |
BIOS type | UEFI AMI |
BIOS memory size | 32 Mbit |
ACPI-Version | 6.5 |
operating conditions | |
Storage temperature range | -20 - 60 °C |
operating temperatur | 0 - 50 °C |
weight and dimensions | |
broad | 305 mm |
depth | 244 mm |
