Compatible processor series | AMD EPYC 7003 |
Maximum number of SMP processors | 1 |
Processor manufacturer | AMD |
Processor Socket | Socket SP3 |
On-board graphics card memory | 512 MB |
On-board graphics card model | Aspeed AST2500 |
Motherboard form factor | ATX |
Component for | Server |
Motherboard chipset family | AMD |
Maximum RDIMM memory | 256 GB |
Number of memory slots | 8 |
Supported memory types | DDR4-SDRAM |
Memory voltage | 1.2 V |
Memory slots type | DIMM |
Operating relative humidity (H-H) | 20 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 10 - 35 °C |
Depth | 244 mm |
Width | 305 mm |
Wi-Fi | No |
Ethernet LAN | Yes |
Number of SATA III connectors | 10 |
TPM connector | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
EPS power connector (8-pin) | Yes |
ATX Power connector (24-pin) | Yes |
ACPI version | 6.3 |
BIOS memory size | 32 Mbit |
BIOS Type | UEFI AMI |
System management BIOS (SMBIOS) version | 3.3.0 |
Supported storage drive interfaces | M.2, SATA III |
VGA (D-Sub) ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 3 |
IPMI LAN (RJ-45) port | Yes |
Serial ports quantity | 1 |
PCI Express x16 (Gen 4.x) slots | 7 |
