Processor Socket | Socket AM4 |
Supported processor sockets | Socket AM4 |
Graphics card | AST2500 |
Graphics card family | ASPEED |
Motherboard chipset family | AMD |
MOTHERBOARD CHIPSET | AMD X570 |
Motherboard form factor | micro ATX |
Unbuffered memory | Yes |
Supported memory types | DDR4-SDRAM |
Memory slots type | DIMM |
Memory voltage | 1.2 |
Number of memory slots | 4 |
Non-ETC | Yes |
Supported memory clock speeds | 3200 |
Maximum internal memory | 32 GB |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 10 - 35 °C |
Depth | 244 mm |
Width | 244 mm |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
LAN controller | Realtek RTL8211E |
Chassis intrusion connector | Yes |
ATX Power connector (24-pin) | Yes |
TPM connector | Yes |
Number of SATA III connectors | 12 |
Number of SATA connectors | 12 |
12V power connector | Yes |
ACPI version | 2.0 |
BIOS Type | UEFI AMI |
Raid Support | Yes |
RAID levels | 0 |
Supported storage drive interfaces | M.2, SATA III |
HDMI ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 3 |
VGA (D-Sub) ports quantity | 1 |
PCI Express x8 slots | 1 |
PCI Express x1 slots | 1 |
PCI Express x16 (Gen 4.x) slots | 1 |
Harmonized System (HS) code | 84733020 |
