Processor manufacturer | AMD |
Processor Socket | Socket sTR5 |
MOTHERBOARD CHIPSET | AMD WRX90 |
audio chip | Realtek ALC1220P |
Motherboard form factor | EEB |
Motherboard chipset family | AMD |
Component for | Workstation |
Windows operating systems supported | Windows 11 |
Memory slots type | DIMM |
Number of memory slots | 8 |
ETC | Yes |
Supported memory types | DDR5-SDRAM |
Memory channels | Octa-channel |
Depth | 330 mm |
Width | 305 mm |
Ethernet interface type | Fast Ethernet |
Ethernet LAN | Yes |
Wi-Fi | No |
CPU fan connector | Yes |
USB 2.0 connectors | 2 |
Front panel audio connector | Yes |
USB 3.2 Gen 2x2 connectors | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
ATX Power connector (24-pin) | Yes |
Number of SATA III connectors | 4 |
TPM connector | Yes |
Number of COM connectors | 1 |
Chassis intrusion connector | Yes |
Number of chassis fan connectors | 5 |
EPS power connector (8-pin) | Yes |
BIOS Type | UEFI AMI |
BIOS memory size | 256 Mbit |
Clear CMOS button | Yes |
Supported storage drive types | HDD & SSD |
Raid Support | Yes |
Supported storage drive interfaces | M.2, SATA III, SlimSAS |
RAID levels | 10 |
Number of HDDs supported | 4 |
Number of storage drives supported | 10 |
USB 2.0 ports quantity | 1 |
USB connector type | USB Type-A |
USB4 Gen 3x2 ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 2 |
VGA (D-Sub) ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 6 |
PCI Express x16 (Gen 5.x) slots | 7 |
Number of M.2 (M) slots | 4 |
Mini DisplayPorts quantity | 2 |
