Processor cores | 64 |
Processor number of cores supported | 64 |
Processor manufacturer | AMD |
Compatible processor series | AMD Ryzen Threadripper Pro 3rd Gen |
Maximum number of SMP processors | 1 |
Processor Socket | Socket SP3 |
Parallel processing technology support | 3-Way SLI |
Compatible operating systems | Windows 10 |
Motherboard form factor | Extended ATX |
Motherboard chipset family | AMD |
MOTHERBOARD CHIPSET | AMD WRX80 |
Cooling type | Passive |
Component for | PC |
Windows operating systems supported | Windows 10 x64 |
Harmonized System (HS) code | 84733020 |
Supported memory clock speeds | 3200 MHz |
Maximum internal memory | 2.05 TB |
ETC | Yes |
Memory channels | Octa-channel |
Number of memory slots | 8 |
Supported memory types | DDR4-SDRAM |
Memory slots type | DIMM |
Depth | 330 mm |
Width | 309.8 mm |
Height | 108 mm |
LAN controller | Intel X550-T2 |
Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
Wi-Fi standards | Wi-Fi 4 (802.11n) |
Ethernet LAN | Yes |
Wi-Fi | Yes |
Ethernet interface type | 10 Gigabit Ethernet |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
USB 2.0 connectors | 2 |
CPU fan connector | Yes |
ATX Power connector (24-pin) | Yes |
Chassis intrusion connector | Yes |
Number of chassis fan connectors | 6 |
TPM connector | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
EPS power connector (8-pin) | Yes |
Number of SATA III connectors | 8 |
Clear CMOS button | Yes |
BIOS Type | UEFI AMI |
BIOS memory size | 256 Mbit |
Drivers included | Yes |
CABLES INCLUDED | SATA, VGA |
Supported storage drive interfaces | SATA III |
Raid Support | Yes |
RAID levels | 10 |
VGA (D-Sub) ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 9 |
Headphone outputs | 1 |
PCI Express x16 slots | 7 |
Number of M.2 (M) slots | 3 |
Trusted Platform Module (TPM) | Yes |
Weight | 572 g |
Number of processors supported | 1 |
