Processor manufacturer | AMD |
Compatible processor series | AMD Ryzen 9000 Series |
Maximum number of SMP processors | 1 |
Processor Socket | Socket AM5 |
Supported processor sockets | Socket AM5 |
Parallel processing technology support | Not supported |
Windows operating systems supported | Windows 10 x64 |
Product colour | Blue |
Motherboard form factor | micro ATX |
Component for | Server/workstation |
MOTHERBOARD CHIPSET | AMD B650E |
Motherboard chipset family | AMD |
Supported memory clock speeds | 4000 |
Number of memory slots | 4 |
ECC сompatibility | ECC & Non-ECC |
Memory slots type | DIMM |
Supported memory types | DDR5-SDRAM |
Memory channels | Dual-channel |
Width | 244 mm |
Depth | 244 mm |
Ethernet interface type | 10 Gigabit Ethernet |
Wi-Fi | No |
Ethernet LAN | Yes |
ATX Power connector (24-pin) | Yes |
USB 2.0 connectors | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Number of chassis fan connectors | 5 |
CPU fan connector | Yes |
12V power connector | Yes |
Number of SATA III connectors | 4 |
USB 3.2 Gen 2x2 connectors | 1 |
Package width | 321 mm |
DFU / User manual | Y |
CABLES INCLUDED | SATA |
RAID levels | 1 |
Supported storage drive interfaces | M.2, SATA III |
Raid Support | Yes |
Number of HDDs supported | 4 |
Supported storage drive types | HDD & SSD |
VGA (D-Sub) ports quantity | 1 |
Port Management LAN | Yes, 1 |
Ethernet LAN (RJ-45) ports | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
COM ports quantity | 1 |
PCI Express x4 (Gen 4.x) slots | 1 |
PCI Express x16 (Gen 5.x) slots | 1 |
