Status | Launched |
Supported memory types | DDR4-SDRAM |
Launch date | Q3'21 |
Servicing status | Baseline Servicing |
System bus rate | 8 GT/s |
Processor manufacturer | Intel |
Processor cores | 4 |
Processor operating modes | 64-bit |
Processor family | Intel Xeon E |
Processor boost frequency | 4.8 GHz |
Processor cache | 8 MB |
Component for | Server/workstation |
Processor threads | 8 |
Processor lithography | 14 nm |
Processor cache type | Smart Cache |
Processor model | E-2334 |
Box | No |
Processor Socket | LGA 1200 (Socket H5) |
Processor ARK ID | 212258 |
Thermal Design Power (TDP) | 65 W |
Cooler included | No |
Processor base frequency | 3.4 GHz |
Discrete graphics card model | Not available |
On-board graphics card | No |
Discrete graphics card | No |
Execute Disable Bit | Yes |
Thermal Monitoring Technologies | Yes |
PCI Express slots version | 4.0 |
PCI Express configurations | 1x16+1x4 |
Supported instruction sets | AVX-512 |
Market segment | Server |
Scalability | 1S |
Idle States | Yes |
Maximum number of PCI Express lanes | 20 |
CPU configuration (max) | 1 |
Commodity Classification Automated Tracking System (CCATS) | G167599 |
Export Control Classification Number (ECCN) | 5A992CN3 |
Maximum internal memory supported by processor | 128 GB |
Memory channels | Dual-channel |
Memory types supported by processor | DDR4-SDRAM |
ETC | Yes |
Tjunction | 100 °C |
Processor package size | 37.5 x 37.5 mm |
Intel® Secure Key | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel Trusted Execution Technology | Yes |
Intel® Boot Guard | Yes |
Intel® OS Guard | Yes |
Intel® Turbo Boost Technology | 2.0 |
Intel® Memory Protection Extensions (Intel® MPX) | Yes |
Enhanced Intel SpeedStep Technology | Yes |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Intel Software Guard Extensions (Intel SGX) | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Intel® Optane™ DC Persistent Memory Supported | No |
Intel® vPro™ Platform Eligibility | Yes |
Intel 64 | Yes |
Intel® Transactional Synchronization Extensions | No |
Intel® Turbo Boost Technology 2.0 frequency | 4.8 GHz |
Maximum Enclave Size Support for Intel® SGX | 0.5 GB |
Maximum internal memory | 128 GB |
Harmonized System (HS) code | 85423119 |
