Processor family | AMD EPYC |
Processor cache | 32 MB |
MOTHERBOARD CHIPSET | AMD B650 Express |
Processor boost frequency | 5.3 GHz |
Processor cores | 8 |
Processor model | 4344P |
Processor frequency | 3.8 GHz |
Processor manufacturer | AMD |
Processor Socket | Socket AM5 |
Intelligent Platform Management Interface (IPMI) support | Yes |
Number of Processors Installed | 1 |
On-board graphics card model | AMD Radeon Graphics |
On-board graphics card | Yes |
On-board graphics card family | AMD Radeon Graphics |
INTERNAL MEMORY | 16 GB |
Maximum internal memory | 192 GB |
Internal memory type | DDR5-SDRAM |
ETC | Yes |
Memory layout (slots x size) | 1 x 16 GB |
Memory slots | 4x DIMM |
Bezel | No |
Motherboard form factor | micro ATX |
Product colour | Black |
Chassis type | Mini Tower |
Rack rails | No |
Rack mounting | No |
Power cable connector 1 | C13 coupler |
Power supply | 400 W |
Power supply input frequency | 50-60 Hz |
Power supply input voltage | 100-240 V |
Number of main power supplies | 1 |
Weight | 10 kg |
Width | 184 mm |
Height | 362 mm |
Depth | 425 mm |
Number of LAN controllers | 2 |
LAN controller | Intel I210 |
Cabling technology | 10/100/1000Base-T(X) |
Wi-Fi | No |
Ethernet interface type | Gigabit Ethernet |
Ethernet LAN | Yes |
BIOS Type | AMI |
PCI Express x16 slots | 1 |
PCI Express x1 slots | 1 |
PCI Express x4 slots | 1 |
Compatible operating systems | Windows Server2022 (64 bit), RedHat Enterprise Linux Server 8.9 ( 64 bit) / 9.3 (64bit) / 9.4 (64bit), SUSE SLES 15.5(64 bit), UBuntu 20.04.6 (64 bit) / 22.04.4 (64 bit) |
Operating system installed | No |
80 PLUS Certification | 80 PLUS Gold |
Supported SSD sizes | M.2 |
SSD size | 2.5" |
Raid Support | Yes |
Optical drive type | No |
Total Storage Capacity | 960 GB |
SSD Capacity | 480 GB |
NVMe | No |
Number of SSDs installed | 2 |
Internal drive bays | 4 |
SSD interface | SATA III |
Number of 5.25" bays | 2 |
Ethernet LAN (RJ-45) ports | 3 |
DisplayPorts quantity | 1 |
S/PDIF out port | No |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
HDMI ports quantity | 1 |
Total number of SATA connectors | 4 |
VGA (D-Sub) ports quantity | 1 |
Serial ports quantity | 1 |
