Number of processors supported | 1 |
Processor Socket | LGA 1200 (Socket H5) |
MOTHERBOARD CHIPSET | Intel C252 |
On-board graphics card memory | 64 MB |
On-board graphics card model | Aspeed AST2600 |
Maximum internal memory | 128 GB |
Memory channels | Dual-channel |
Supported DIMM module capacities | 8GB |
Supported memory types | DDR4-SDRAM |
Number of DIMM slots | 4 |
Supported UDIMM clock speeds | 2666 |
Certification | BSMI, CE, FCC(Class A) |
Chassis type | Rack (1U) |
Product colour | Silver |
Power supply | 450 W |
80 PLUS Certification | 80 PLUS Titanium |
Storage relative humidity (H-H) | 20 - 90% |
Operating temperature (T-T) | 10 - 35 °C |
Storage temperature (T-T) | -40 - 70 °C |
Height | 44 mm |
Depth | 497 mm |
Weight | 15.2 kg |
Width | 439.5 mm |
Ethernet interface type | Fast Ethernet |
Ethernet LAN | Yes |
LAN controller | Intel® I210-AT |
PCI Express slots version | 3.0 |
Number of M.2 (M) slots | 1 |
SSD form factor | M.2 |
Storage drive sizes supported | M.2 |
Supported storage drive interfaces | M.2, Serial ATA III |
Supported storage drive types | HDD & SSD |
Hot-swap HDD bays | Yes |
Number of 3.5" bays | 4 |
Number of storage drives supported | 7 |
COM ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Number of SATA III connectors | 6 |
Ethernet LAN (RJ-45) ports | 2 |
HDMI ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
