Processor Socket | Socket SP5 |
Processor family | AMD |
Built-in processor | No |
Compatible processor series | AMD EPYC 9004 |
AMD Opteron series | 9000 |
Processor manufacturer | AMD |
On-board graphics card memory | 64 MB |
On-board graphics card model | Aspeed AST2600 |
Trusted Platform Module (TPM) | Yes |
Integrated BMC with IPMI | Yes |
Trusted Platform Module (TPM) version | 2.0 |
Supported DIMM module capacities | 64GB |
Supported memory types | DDR5-SDRAM |
Maximum RDIMM memory | 3.07 TB |
Number of DIMM slots | 24 |
Certification | BSMI, CE, CB, C-Tick, FCC(Class A) |
Cooling type | Active |
Chassis type | Rack (1U) |
LED indicators | Yes |
Product colour | Steel |
Redundant power supply (RPS) support | Yes |
Number of redundant power supplies supported | 2 |
80 PLUS Certification | 80 PLUS Platinum |
Power supply | 2600 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Operating temperature (T-T) | 10 - 35 °C |
Operating relative humidity (H-H) | 20 - 90% |
Storage relative humidity (H-H) | 20 - 90% |
Storage temperature (T-T) | -40 - 60 °C |
Height | 43.9 mm |
Width | 449 mm |
Depth | 842.5 mm |
Weight | 14.9 kg |
Ethernet LAN data rates | 10000 Mbit/s |
Ethernet LAN | Yes |
Ethernet interface type | 10 Gigabit Ethernet |
LAN controller | Intel X710-AT2 |
PACKAGE WEIGHT | 19.9 kg |
PCI Express slots version | 5.0 |
Number of M.2 (M) slots | 2 |
PCI Express x8 slots | 1 |
PCI Express x4 slots | 1 |
PCI Express x16 slots | 1 |
Storage drive sizes supported | 2.5 |
Number of storage drives supported | 14 |
Supported storage drive interfaces | Serial ATA, Serial Attached SCSI (SAS) |
Supported storage drive types | HDD & SSD |
Hot-swap HDD bays | Yes |
VGA (D-Sub) ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 3 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
IPMI LAN (RJ-45) port | Yes |
