Number of Processors Installed | 1 |
Processor manufacturer | Intel |
Processor cores | 4 |
Processor frequency | 3.4 GHz |
Processor boost frequency | 4.8 GHz |
Processor model | E-2334 |
Processor cache | 8 MB |
Processor family | Intel Xeon E |
Internal memory type | DDR4-SDRAM |
Memory slots | 4x DIMM |
INTERNAL MEMORY | 16 GB |
Memory clock speed | 3200 MHz |
Buffered memory type | Unregistered (unbuffered) |
ETC | Yes |
Maximum internal memory | 128 GB |
Memory layout (slots x size) | 1 x 16 GB |
Rack rails | Yes |
Product colour | Black |
Chassis type | Rack (1U) |
Rack mounting | Yes |
Power cable current | 10 A |
Power supply | 700 W |
Redundant power supply (RPS) support | No |
Power cable connector 2 | C14 coupler |
Power cable connector 1 | C13 coupler |
Power supply input voltage | 200 - 240 V |
Number of main power supplies | 1 |
Power cable length | 2 m |
Height | 42.8 mm |
Width | 482 mm |
Ethernet LAN | Yes |
Cabling technology | 10/100/1000Base-T(X) |
LAN controller | Broadcom 5720 |
Ethernet interface type | Gigabit Ethernet |
Remote administration | iDRAC9 Basic |
PCI Express x8 slots | 1 |
PCI Express x16 slots | 1 |
Compatible operating systems | Canonical® Ubuntu® Server LTS
Citrix® Hypervisor
Microsoft® Windows Server® with Hyper-V
RedHat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi® |
Operating system installed | No |
Storage drive adapter included | Yes |
Hot-Plug support | Yes |
Supported RAID controllers | PERC H355 |
SSD size | 2.5" |
Drive Writes Per Day (DWPD) | 1 |
SSD Capacity | 480 GB |
Storage drive adapter type | 2.5" - 3.5" |
Number of SSDs supported | 4 |
Total Storage Capacity | 480 GB |
SSD interface | SATA III |
Raid Support | No |
Optical drive type | No |
Supported SSD sizes | 3.5" |
Number of SSDs installed | 1 |
Ethernet LAN (RJ-45) ports | 2 |
USB 2.0 ports quantity | 2 |
VGA (D-Sub) ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
Bytes per Sector | 512 |
Data Transfer Rate | 6 Gbit/s |
Carbon emissions, energy usage (kg of CO2e) | 1470 |
Carbon emissions, manufacturing (kg of CO2e) | 505 |
Carbon emissions, logistics (kg of CO2e) | 110 |
Carbon emissions, end-of-life (kg of CO2e) | 17 |
PAIA version | 1.3.2, 2022 |
Total carbon emissions, standard deviation (kg of CO2e) | 935 |
Total carbon emissions, w/o use phase (kg of CO2e) | 632 |
Total carbon footprint (kg of CO2e) | 2100 |
