Processor frequency | 2.6 GHz |
Processor family | Intel Xeon E |
Processor manufacturer | Intel |
Processor cores | 4 |
Processor model | E-2414 |
Number of Processors Installed | 1 |
MOTHERBOARD CHIPSET | Intel C262 |
Processor cache | 12 MB |
Internal memory type | DDR5-SDRAM |
ETC | Yes |
Memory slots | 4x DIMM |
Memory clock speed | 4800 MHz |
Maximum internal memory | 128 GB |
Memory layout (slots x size) | 1 x 16 GB |
INTERNAL MEMORY | 16 GB |
Redundant fans support | No |
Chassis type | Ultra Micro Tower |
Power supply input voltage | 100 - 240 V |
Power supply | 180 W |
Power supply input frequency | 50 - 60 Hz |
Redundant power supply (RPS) support | No |
Weight | 7.97 kg |
Depth | 467 mm |
Height | 255.4 mm |
Width | 377 mm |
LAN controller | Broadcom BCM5719 |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
Trusted Platform Module (TPM) | Yes |
Trusted Platform Module (TPM) version | 2.0 |
Remote administration | iLO 6 ASIC |
Compatible operating systems | Microsoft Windows Server 2022: Essentials, Standard, Datacenter
Red Hat Enterprise Linux (RHEL): 8.8, 9.2 (64 bit, includes KVM)
VMware vSphere: 8.0 U2
Canonical Ubuntu 20.04 & 22.04 |
Operating system installed | No |
Maximum storage capacity | 16 TB |
RAID levels | 10 |
Hot-Plug support | No |
Supported HDD sizes | 3.5" |
Optical drive type | No |
Number of HDDs supported | 4 |
HDD interface | SATA |
Total Storage Capacity | 0 GB |
Raid Support | Yes |
Ethernet LAN (RJ-45) ports | 4 |
DisplayPorts quantity | 1 |
VGA (D-Sub) ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
