Product colour | Black |
Housing material | Aluminium |
Easy to install | Yes |
Depth | 656 mm |
Height | 579 mm |
Width | 135 mm |
Weight | 3.72 kg |
Package depth | 122 mm |
PACKAGE WEIGHT | 4.3 kg |
Package Type | Box |
Package height | 423 mm |
Package width | 333 mm |
Package net weight | 4.3 kg |
HEIGHT ADJUSTMENT | Yes |
Swivel angle range | -90 - 90° |
Tilt angle range | -90 - 90° |
Angle of rotation | 360° |
Tilt adjustment | Yes |
Swivelling | Yes |
Rotating | Yes |
Depth adjustment range | 88 - 625 mm |
Adjustable Depth | Yes |
Height adjustment range | 200 - 520 mm |
Height adjustment type | Gas spring |
Cable management | Yes |
Number of arms | 1 |
Minimum weight | 1 kg |
Width adjustment range | 0 - 1074 mm |
Warranty period | 10 year(s) |
Products per master (outer) case | 4 pc(s) |
Country of origin | China |
Harmonized System (HS) code | HS7326909890 |
Master (outer) case width | 355 mm |
Master (outer) case gross weight | 17.9 kg |
Master (outer) case length | 290 mm |
Master (outer) case net weight | 14.9 kg |
Master (outer) case height | 490 mm |
Warnings | Do not exceed the maximum user weight recommended by the manufacturer. |
Mounting Type | Desk |
Panel mounting interface | 100 x 100 |
Minimum VESA mount | 75 x 75 mm |
Mounting | Clamp/Grommet |
Maximum screen size | 124.5 cm (49") |
Minimum screen size | 43.2 cm (17") |
Distance to the wall (min) | 11.9 cm |
Desk thickness (max) | 5.5 cm |
Desk thickness (min) | 1 cm |
Maximum weight capacity | 18 kg |
Maximum VESA mount | 100 x 100 mm |
Distance to the wall (max) | 65.6 cm |
Number of displays supported | 1 |
Grommet mount desk thickness (max) | 5.5 cm |
Clamp mount desk thickness (max) | 5 cm |
Maximum weight capacity (per curved/ultra-wide display) | 15 kg |
