Product colour | Silver |
Housing material | Steel |
Height | 505 mm |
Depth | 615 mm |
Package depth | 116 mm |
Package width | 465 mm |
PACKAGE WEIGHT | 6.1 kg |
Package height | 570 mm |
Swivel angle range | -90 - 90° |
Tilt angle range | -90 - 90° |
Tilt adjustment | Yes |
HEIGHT ADJUSTMENT | Yes |
Angle of rotation | 360° |
Swivelling | Yes |
Swivel Angle | 180° |
Rotating | Yes |
Depth adjustment range | 0 - 615 mm |
Height adjustment type | Gas spring |
Height adjustment range | 170 - 505 mm |
Minimum weight | 1 kg |
Width adjustment range | 0 - 1100 mm |
Products per master (outer) case | 2 pc(s) |
Master (outer) case height | 250 mm |
Master (outer) case length | 480 mm |
Master (outer) case gross weight | 16.5 kg |
Master (outer) case width | 590 mm |
Master (outer) case net weight | 12.2 kg |
Country of origin | China |
Harmonized System (HS) code | 7326909890 |
Panel mounting interface | 100 x 100 mm |
Number of displays supported | 2 |
Distance to the wall (min) | 12.6 cm |
Mounting Type | Desk |
Maximum weight capacity | 9 kg |
Distance to the wall (max) | 65.1 cm |
Maximum screen size | 81.3 cm (32") |
Mounting | Clamp/Grommet |
Minimum screen size | 25.4 cm (10") |
Minimum VESA mount | 75 x 75 mm |
Maximum VESA mount | 100 x 100 mm |
Desk thickness (max) | 8.5 cm |
Desk thickness (min) | 1 cm |
