Compatible processor series | AMD Ryzen™ 5 |
Supported processor sockets | Socket AM4 |
Processor Socket | Socket AM4 |
Processor manufacturer | AMD |
Parallel processing technology support | Not supported |
Cooling type | Passive |
Motherboard form factor | micro ATX |
Audio output channels | 7.1 channels |
Windows operating systems supported | Windows 10 |
Motherboard chipset family | AMD |
Power source type | ATX |
MOTHERBOARD CHIPSET | AMD A520 |
Product colour | Black |
Supported memory clock speeds | 3400 |
Maximum internal memory | 64 GB |
Memory channels | Dual-channel |
Supported memory types | DDR5-SDRAM |
Unbuffered memory | Yes |
Number of memory slots | 2 |
Supported memory clock speed (max) | 5100 MHz |
Memory slots type | DIMM |
Depth | 193 mm |
Width | 236 mm |
Ethernet LAN | Yes |
Wi-Fi | No |
Ethernet interface type | Gigabit Ethernet |
Peripheral (Molex) power connectors (4-pin) | 1 |
12V power connector | Yes |
Number of chassis fan connectors | 1 |
Number of COM connectors | 1 |
Number of SATA III connectors | 4 |
ATX Power connector (24-pin) | Yes |
Front panel audio connector | Yes |
CPU fan connector | Yes |
TPM connector | Yes |
USB 2.0 connectors | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
BIOS Type | UEFI AMI |
Package width | 270 mm |
Package height | 51.5 mm |
PACKAGE WEIGHT | 880 g |
Package depth | 263 mm |
CABLES INCLUDED | SATA |
Raid Support | Yes |
Supported storage drive interfaces | M.2, SATA III |
Supported storage drive types | HDD & SSD |
RAID levels | 10 |
Number of storage drives supported | 5 |
Number of HDDs supported | 4 |
Line-in | Yes |
Ethernet LAN (RJ-45) ports | 1 |
HDMI version | 2.1 |
Microphone in | Yes |
PS/2 ports quantity | 2 |
Headphone outputs | 1 |
HDMI ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
USB 2.0 ports quantity | 2 |
PCI Express x16 (Gen 3.x) slots | 1 |
Number of M.2 (M) slots | 1 |
PCI Express x1 (Gen 3.x) slots | 1 |
