Certification | FCC Part 15 Subpart B, ANSI C63.4-2014
CE EN50130-4, EN 61000-3-2,EN 61000-3-3 |
Rack capacity | 1U |
Rack mounting | Yes |
Product colour | Black |
Power consumption (typical) | 10 W |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | -10 - 55 °C |
Weight | 1.6 kg |
Width | 265 mm |
Height | 48 mm |
Depth | 246 mm |
Supported resolutions | 1920 x 1080px, 1280 x 1024px, 1280 x 720px, 1024 x 768px |
Number of users | 16 user(s) |
Video formats supported | H.265 |
Output bandwidth | 40 Mbit/s |
Video input channels | 8 channels |
Audio formats supported | G.726 |
Maximum Resolution | 1920 x 1080 pixels |
Input bandwidth | 50 Mbit/s |
Number of simultaneously playbacked channels | 8 channels |
Wi-Fi standards | 802.11a |
Wi-Fi band | Single-band (2.4 GHz) |
Wi-Fi | Yes |
Wi-Fi data rate (max) | 144 Mbit/s |
Ethernet LAN data rates | 10 |
HDMI ports quantity | 1 |
Audio output | 1 |
Supported network protocols | TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP |
USB 2.0 ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
DC-in jack | Yes |
VGA (D-Sub) output ports | 1 |
Maximum storage capacity | 6 TB |
Number of HDDs supported | 1 |
