Product colour | Black |
On/off switch | No |
Rack mounting | 1U |
Power consumption (max) | 5 W |
Rated Current | 1.5 A |
Output voltage | 12 V |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | -10 - 55 °C |
Height | 45 mm |
Weight | 578.5 g |
Depth | 148.2 mm |
Width | 246.2 mm |
Supported resolutions | 1920 x 1080, 1280 x 720, 1440 x 900, 1280 x 1024 |
Dedicated application | VIGI (Google Play/AppStore) |
Onvif standard | Yes |
Output bandwidth | 60 Mbit/s |
Video input channels | 16 channels |
Input bandwidth | 80 Mbit/s |
Video codecs | H.265+/H.265/H.264+/H.264 |
Image viewer | Yes |
Maximum Frame Rate | 60 fps |
Audio recording | Yes |
Audio system | 2-way |
Maximum Resolution | 1920 x 1080 pixels |
Two-way talk | Yes |
Installation instruction | Yes |
Storage drive caddy included | Yes |
AC adapter included | Yes |
Mouse included | Yes |
DFU / User manual | Y |
Wi-Fi | No |
HDD interface | SATA III |
Maximum storage capacity | 10 TB |
Number of HDDs supported | 1 |
DC-in jack | Yes |
Ethernet LAN data rates | 10,100 Mbit/s |
Ethernet LAN (RJ-45) ports | 1 |
Audio RCA inputs | 1 |
Audio RCA outputs | 1 |
Supported network protocols | TCP/IP, DHCP, DNS, NTP, UPnP |
HDMI ports quantity | 1 |
VGA (D-Sub) output ports | 1 |
USB 2.0 ports quantity | 2 |
