management functions | |
Switch-Typ | Managed |
switch level | L2 |
Eigenschaft | Power over Ethernet (PoE) |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 48 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Quantity of SFP module slots | 4 |
network | |
data transmission | |
Routing/Switching Capacity | 104 Gbit/s |
passage | 77,37 Mpps |
MAC-Adressentabelle | 16000 Eintragungen |
Latency (10-100Mbps) | 5,2 µs |
Latency (1Gbps) | 2,8 µs |
Data packet buffer memory | 1,5 MB |
safety | |
DHCP functions | DHCP client |
Design | |
form factor | 1U |
Services | |
processor | ARM Cortex-A9 |
processor clock speed | 800 MHz |
storage type | SDRAM |
storage capacity | 512 MB |
Flash memory | 256 MB |
power | |
energy source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power consumption (max.) | 462,5 W |
Power Over Ethernet (PoE) | |
Overall Power over Ethernet (PoE) | 370 W |
weight and dimensions | |
broad | 351 mm |
depth | 443 mm |
height | 43,9 mm |
Weight | 4,94 kg |
logistic data | |
Goods tariff number (HS) | 85176990 |
