Certification | FCC, CE |
DIN rail mounting | Yes |
Rack mounting | No |
Product colour | Blue |
Housing material | Metal |
International Protection (IP) code | IP30 |
Wall mountable | Yes |
Power consumption (typical) | 6.72 W |
Redundant power supply (RPS) support | Yes |
Operating temperature (T-T) | -40 - 75 °C |
Heat dissipation | 23 BTU/h |
Storage temperature (T-T) | -40 - 75 °C |
Operating relative humidity (H-H) | 5 - 95% |
Storage relative humidity (H-H) | 5 - 95% |
Switch layer | L2 |
Switch type | Unmanaged |
Quality of Service (QoS) support | Yes |
Depth | 87 mm |
Weight | 476 g |
Height | 135 mm |
Width | 32 mm |
Cable types supported | Cat6 |
MAC address auto-learning supported | Yes |
MAC address auto-aging supported | Yes |
Copper ethernet cabling technology | 100BASE-TX |
Networking standards | IEEE 802.3x |
Full duplex | Yes |
Auto-negotiation | Yes |
Broadcast storm control | Yes |
10G support | No |
Auto MDI/MDI-X | Yes |
Flow control support | Yes |
Gigabit Ethernet (copper) ports quantity | 8 |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Terminal block port | Yes |
Harmonized System (HS) code | 85176990 |
Jumbo frames | 9000 |
Switching capacity | 16 Gbit/s |
Throughput | 11.9 Mpps |
Jumbo Frames support | Yes |
Store-and-forward | Yes |
MAC Address Table | 4000 entries |
Power Over Ethernet (PoE) | No |
