Certification | CE, FCC, RoHS |
Rack mounting | Yes |
Stackable | No |
Form factor | 1U |
Number of fans | 2 fan(s) |
LED indicators | LAN |
Product colour | Black |
Power consumption (max) | 217.22 W |
Power source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power supply included | Yes |
Operating temperature (T-T) | 0 - 40 °C |
Heat dissipation | 741.15 BTU/h |
Storage relative humidity (H-H) | 5 - 90% |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Switch type | Unmanaged |
Width | 440 mm |
Depth | 180 mm |
Height | 44 mm |
Auto MDI/MDI-X | Yes |
Copper ethernet cabling technology | 1000BASE-T |
MAC address auto-learning supported | Yes |
MAC address auto-aging supported | Yes |
10G support | No |
Auto-negotiation | Yes |
Networking standards | IEEE 802.3at |
Package depth | 528 mm |
Package height | 80 mm |
Package width | 250 mm |
Package Type | Box |
CABLES INCLUDED | LAN (RJ-45) |
PACKAGE WEIGHT | 2.96 kg |
Manual | Yes |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Combo SFP ports quantity | 2 |
Gigabit Ethernet (copper) ports quantity | 2 |
Basic switching RJ-45 Ethernet ports quantity | 20 |
Fast Ethernet (copper) ports quantity | 16 |
Harmonized System (HS) code | 85176990 |
Jumbo frames | 10000 |
Jumbo Frames support | Yes |
Switching capacity | 7.2 Gbit/s |
Forwarding rate | 5.36 Mpps |
Store-and-forward | Yes |
Packet buffer memory | 4.1 MB |
MAC Address Table | 8000 entries |
Power over Ethernet (PoE) power per port | 30 W |
Power over Ethernet plus (PoE+) ports quantity | 16 |
Total Power over Ethernet (PoE) budget | 192 W |
Power Over Ethernet (PoE) | Yes |
