WAN connection | |
Eigenschaft | Unterstützt Mac-Betriebssysteme |
WAN connection type | RJ-45 |
Wireless LAN functions | |
WiFi band | Dual-Band (2,4 GHz/5 GHz) |
Top WLAN-Standard | Wi-Fi 5 (802.11ac) |
WLAN data transfer rate (max.) | 867 Mbit/s |
WLAN-Standards | 802.11a, 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
WLAN data transfer rate (first band) | 300 Mbit/s |
WLAN data transfer rate (second band) | 867 Mbit/s |
network | |
Interface type Ethernet LAN | Gigabit Ethernet |
Ethernet LAN data transfer rates | 1000 Mbit/s |
wiring technology | 10/100/1000Base-T(X) |
mesh standard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
VPN-Server | PPTP VPN, OpenVPN |
Maximale Sendeleistung (2,4 GHz) | 20 dBmW |
Maximale Sendeleistung (5 GHz) | 23 dBmW |
mobile network | |
Cellular Network Generation | 4G |
3G standards | DC-HSPA+, HSPA+, UMTS |
4G-Standard | LTE-TDD & LTE-FDD |
Supported UMTS bandwidths | 700,800,850,900,1800,2100,2600 MHz |
supported 4G bandwidths | 700,800,850,1800,2100,2600 MHz |
SIM card type | MicroSIM |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 4 |
management functions | |
safety | |
Supported security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
logs | |
Supported network protocols | IPv4, IPv6 |
Design | |
Product color | Schwarz |
product type | Desktop-/Pol-Router |
scope of delivery | |
Supplied cables | LAN (RJ-45) |
Antenna | |
The Antenna Design | Extern |
number of antennas | 2 |
features | |
certification | CE, RoHS |
power | |
energy source | Gleichstrom |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
output voltage | 12 V |
output current | 1,5 A |
operating conditions | |
operating temperatur | 0 - 40 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
system requirement | |
Supports Windows operating systems | Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
weight and dimensions | |
broad | 202 mm |
depth | 141 mm |
height | 33,6 mm |
package weight | 810 g |
packaging type | Box |
logistic data | |
Goods tariff number (HS) | 85176990 |
