The Lenovo ThinkCentre M90q G5 is a versatile business computer packed into a compact Tiny chassis. Despite its small size, the device features a free PCIe 4.0 x8 slot for exciting expansion cards. Thanks to the available M.2 2280 slot, internal SSD storage can be easily expanded. The device can dock directly with the Lenovo Tiny-in-One (TIO) monitor without the need for tools, creating a convenient all-in-one PC solution. A special feature of this model is the inclusion of two RJ-45 Ethernet network ports.
Key Features:
- Operating System: Windows 11 Pro 64-bit
- Processor: Intel Core i5-14500T (14C/20T/24MB)
- Processor specifications: 6xP-core 1.7/4.8GHz, 8xE-core 1.2/3.4GHz
- Chipset: Intel Q670
- Graphics: Integrated Intel UHD Graphics 770
- Intel® vPro® Enterprise
- Memory: 16GB DDR5 5600MHz SODIMM (1x16)
- Maximum Memory: 64GB 5600MHz (2x32GB)
- Storage: 512GB SSD M.2 2280 PCIe 4.0x4 Performance NVMe Opal 2.0
- One free M.2 2280 SSD slot
- Internal 2W Premium speaker
- LAN #1 Intel Gigabit Ethernet 100/1000
- LAN #2 Realtek 2.5 Gigabit Ethernet RTL8125BGS
- WLAN Intel Wi-Fi 6E AX211 802.11ax 2x2 + BT 5.3
- Included: Lenovo USB keyboard and optical USB mouse
- Front Panel: 1xUSB-C Gen2, 2xUSB-A Gen2, 3.5mm headphone/microphone combo
- Back Panel: 2xDisplayPort, HDMI 2.1 TMDS, 2xUSB-A Gen1, 2XUSB-A Gen2, RJ-45
- One free PCIe 4.0 x8 low profile expansion slot
- Integrated TPM 2.0 security chip, TCG/FIPS 140-2 certified
- Kensington security lock slot (3x7mm)
- Included: VESA Mount bracket
- External power supply: 90W 89%
- Military-grade durability: MIL-STD-810H
- Basic warranty: 3 years Premier NBD on-site
- Weight: 1.25kg
Lenovo CO2 Offset Gen2 emission compensation
- The carbon dioxide emissions generated during the manufacturing, transportation, and electricity consumption of this device throughout its lifecycle have been compensated through the global Climeco organization, supporting UN-approved environmental projects.
Environmental and energy certifications
- ENERGY STAR® 8.0, EPEAT™ Gold Registered, ErP Lot 3, RoHS compliant, TCO Certified 9.0
Product life cycle used in emission assessments, years | 4 |
Product life cycle CO2 emissions, kg (manufacturer?s estimate) | 302 |
RAID-i tased | 0/1 |
RAID-i kontroller | Yes |
Operatsioonisüsteem (komplektis) | Windows 11 Pro |
Liidesed | Ethernet (RJ-45) |
Protsessori seeria | Intel Core i5 |
Protsessori tuumade arv | 14 |
Pooljuhtketta tüüp | M.2 PCIe NVMe |
Salvestusmaht | 512 GB SSD |
Sisseehitatud mälu | 16 GB |
Paigaldatud mälu maksimaalne maht, GB | 64 GB |
Graafika adapter | Intel UHD Graphics 770 |
Protsessori taktsagedus, GHz | 1.70 |
Emaplaadi kiibistik | Intel Q670 |
Mälupesad (vabad) | 1 |
Protsessori mudel | Intel Core i5-14500T (Max. 4.80GHz, 24M, 14C) |
Vooluadapter, W | 90 |
Protsessori tootja | Intel |
Mõõtmed W x D x H, mm | 179 x 182.9 x 36.5 |
Bluetooth-i versioon | 5.3 |
Paigaldatud mälutüüp | DDR5 |
Mälu taktsagedus, MHz | 4800 |
Kaal, g | 1250 |
Intel Virtualization tehnoloogia | VT-x / VT-d / VT-rp |
Graafikaadapteri tüüp | Intel UHD Graphics |
WLAN-i tüüp | Intel Wi-Fi 6E AX211, 802.11ax 2x2 |
USB-A (USB 3.2) portide arv | 6 |
Inteli nutikas vahemälu, MB | 24 |
Intel Turbo Boost, GHz | 4.80 |
HDMI portide arv | 1 |
Mälupesad | 2 |
DisplayPorts portide arv | 1 |
WLAN antennid | 2x2 |
Esitustuumade arv | 6 |
Efektiivsete tuumade arv | 8 |
USB-C (USB 3.2) ports quantity | 1 |
Usaldusväärse platvormi mooduli (TPM) versioon | 2.0 |
Green certifications | TCO 9.0 |
Kõlari võimsus, W | 2 |
Ethernet LAN (RJ-45) portide arv | 2 |
Juhtmeta LAN (WLAN) | Yes |
Optiline seadme | No |
Sisseehitatud kaardilugeja | No |
Bluetooth (sinihammas) | Yes |
Intel HyperThreading tehnoloogia | Yes |
Spetsiaalne videomälu (GB) | Uses system memory |
Intel vPro | Yes |
Kaabliluku pesa | Yes |
Wi-Fi | Yes |
Sisseehitatud kõlarid | Yes |
