Garantii periood | 2 year(s) |
Sertifitseerimine | IEC 62196, IEC 62752, IEC 60309, EN 300 220-1/2, EN 300 328, EN 301 489-1/17, EN 301 489-1/3,
EN 301 489-1/52, EN 301 511 |
Vehicle charging standard | Mode 3 |
Direct current failure monitoring | Yes |
Vehicle connection plug | Type 2 |
Mechanical impact protection code | IK10 |
Püsivara uuendatav | Yes |
Ülevoolukaitse | Yes |
Rahvusvahelise kaitse (IP) kood | IP54 |
Wi-Fi | Yes |
Toiteallika tüüp | AC |
Integrated energy meter | Yes |
Integreeritud laadimiskaabel | Yes |
Korpuse materjal | Aluminium |
Korpuse värv | Grey |
Sisseehitatud ekraan | Yes |
Kaabli värvus | Black |
LED-indikaatorid | Fault |
Ekraani tehnoloogia | LED |
Paigaldus/monteerimine | Wall |
Minimum operating power (single-phase) | 1.4 kW |
Maksimaalne laadimisvõimsus | 22000 W |
Maximum operating current (three-phase) | 32 A |
Single-phase output voltage supported | 230 V |
Three-phase output voltage supported | 400 V |
Faaside arv | 3 |
Maximum operating power (three-phase) | 22 kW |
Maximum operating current per phase | 32 A |
Maximum operating power (single-phase) | 7.2 kW |
Charging cable length | 7.5 m |
Kõrgus | 338 mm |
Sügavus (paksus) | 73 mm |
Kaal | 6.72 kg |
Laius | 211 mm |
