Type Outdoor | Video interface HDCVI | Sensor size 2 MP CMOS | Focal Length 2.8 mm; 3.6 mm | Lens Mount M12 | Min. Illumination 0.001 Lux | Effective pixels 1920 (H) × 1080 (V) | Electronic Shutter Speed PAL: 1/25 s–1/100000 s ; NTSC: 1/30 s–1/100000 s | Power supply requirements 12 VDC ± 30% | Colour White | Dimensions 161.3 × 69.7 × 70.0 mm
Kirjeldus | HAC-HFW1200C-0280B-S6
CAMERA HDCVI 1080P IR BULLET/ HAC-HFW1200C-0280B-S6 DAHUA
2MP IR HDCVI Fixed-focal Bullet Camera
> Max. 30 fps@1080p.
> Smart IR Illumination.
> 30 m illumination distance.
> Super Adapt.
> 3.6 mm fixed lens (2.8mm optional).
> CVI/CVBS/AHD/TVI switchable.
> IP67, 12 VDC. |
Tootja lehekülg | www.dahuasecurity.com/ceen/products/All-Products/HDCVI-Cameras/Lite-Series/1080P/1080-P/HAC-HFW1200C(-A)=S6 |
Mudel | HAC-HFW1200C-0280B-S6 |
Kaamera disain | Bullet |
Võrgukaamera tüüp | Outdoor |
Videoliides | HDCVI |
Efektiivseid megapiksleid | 2 Mega Pixel |
Võrgukaamera eraldusvõime | 2 - 4MP |
Sensori suurus | 2 MP CMOS |
Objektiivi fokaalvahemik | 3.6 - 4mm |
Objektiivikinnitus | M12 |
Minimaalne valgustus | 0.001 Lux |
IR valgustus | Yes |
Efektiivsed pikslid | 1920 (H) × 1080 (V) |
Elektrooniline säriaeg | PAL: 1/25 s–1/100000 s ; NTSC: 1/30 s–1/100000 s |
Toiteadapteri/ploki nõue | 12 VDC ± 30% |
Energiatarbimine | 2.8 Watts |
Keskkond | Outdoor |
Värvus | White |
Mõõtmed (füüsilised parameetrid) | 161.3 × 69.7 × 70.0 mm |
Kaal | 0.19 kg |
Brutokaal | 0.29 kg |
Täiskirjeldus | Type Outdoor|Video interface HDCVI|Sensor size 2 MP CMOS|Focal Length 2.8 mm; 3.6 mm|Lens Mount M12|Min. Illumination 0.001 Lux|Effective pixels 1920 (H) × 1080 (V)|Electronic Shutter Speed PAL: 1/25 s–1/100000 s ; NTSC: 1/30 s–1/100000 s|Power supply requirements 12 VDC ± 30%|Colour White|Dimensions 161.3 × 69.7 × 70.0 mm |
Kategooria kood | HSC |
