Type Fixed Dome/Outdoor | Sensor size 1/2.7 inch CMOS | Focal Length 2.8mm | Lens Mount M12 | Min. Illumination 0.01 Lux | Electronic Shutter Speed PAL: 1/25s–1/100000s; NTSC: 1/30s–1/100000s | 1xBNC | Power supply requirements 12 VDC | Dimensions φ109.9 mm × 81.0 mm
Kirjeldus | - 1/2.7" CMOS, 2880 × 1620@ 25FPS
- Sensitivity: 0.01 Lux/F1.6, 30IRE, 0 Lux IR on
- Fixed 2.8 mm Lens (111°)
- True Day / Night with ICR Filter, Smart IR LED up to 30 m
- BLC / HLC / DWDR, 2D DNR
- Video output choices of CVI/TVI/AHD/CVBS by one BNC port
- Dome design, metal shell, IP67, IK10, outdoor/indoor use, -40°C~+60°C
- Power 12 VDC, 3.5W max
|
Tootja lehekülg | www.dahuasecurity.com/ceen/products/All-Products/HDCVI-Cameras/Lite-Series/5MP/Starlight/HAC-HDBW1500E=S2 |
Mudel | HAC-HDBW1500E-0280B-S2 |
Kaamera disain | Dome |
Võrgukaamera tüüp | Fixed Dome/Outdoor |
Efektiivseid megapiksleid | 5 Mega Pixel |
Võrgukaamera eraldusvõime | 5 - 7MP |
Sensori suurus | 1/2.7 inch CMOS |
Objektiivi fokaalvahemik | 2.8mm |
Objektiivikinnitus | M12 |
Minimaalne valgustus | 0.01 Lux |
IR valgustus | Yes |
Elektrooniline säriaeg | PAL: 1/25s–1/100000s; NTSC: 1/30s–1/100000s |
BNC liides | 1 |
Toitevalikud | 12V |
Toiteadapteri/ploki nõue | 12 VDC |
Energiatarbimine | 3.5 Watts |
Keskkond | Outdoor |
Mõõtmed (füüsilised parameetrid) | φ109.9 mm × 81.0 mm |
Kaal | 0.31 kg |
Brutokaal | 0.46 kg |
Üksuse kasti laius | 0.125 |
Üksuse kasti pikkus | 0.14 |
Üksuse kasti kõrgus | 0.115 |
Täiskirjeldus | Type Fixed Dome/Outdoor|Sensor size 1/2.7 inch CMOS|Focal Length 2.8mm|Lens Mount M12|Min. Illumination 0.01 Lux|Electronic Shutter Speed PAL: 1/25s–1/100000s; NTSC: 1/30s–1/100000s|1xBNC|Power supply requirements 12 VDC|Dimensions φ109.9 mm × 81.0 mm |
Kategooria kood | HSC |
