Type HDTV/Megapixel/Outdoor | Pixel Resolution 5 Mega Pixel | Focal Length 2.8 mm | IR Illumination | Sensor size 1/2.7" | Microphone Built-in | Lens Mount M12 | Min. Illumination 0.003 Lux | Effective pixels 2960 (H) × 1668 (V) | Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s | 1xAudio-In | 1xAudio-Out | 1xRJ45 | 1xAlarm In | 1xAlarm Out | Supports card capacities up to 256GB | Power options PoE/12V | Power supply requirements PoE / 12VDC power, 7.3W max | Environment Outdoor | Operating temperature range -40°C~+60°C | Colour White
| Tootja lehekülg | www.dahuasecurity.com/products/All-Products/Network-Cameras/WizSense-Series/TiOC/IPC-HDW3549H-AS-PV=S4 |
| Kirjeldus | 1/2.7”5Megapixel progressive CMOS, 2960 × 1668 @20FPS
Minimum illumination: 0.003 Lux @F1.0
True Day/Night (ICR), BLC / HLC / True WDR 120dB /3D DNR
2.8 mm fixed lens (97°)
Up to 30 meters IR / visible white LED Illumination
H.265; H.264; H.264H; H.264B; MJPEG encoding, ONVIF(Profile S/Profile G);CGI;P2P;Milestone;Genetec
Built-in Mic and spearker
Red and blue flashlight alarm + siren sound
1/1 Alarm I/O, 1/1 audio I/O
Micro SD card up to 256GB supported
Metal case, IP67, -40°C~+60°C, PoE / 12VDC power, 7.3W max
Smart capabilities: Tripwire; intrusion (Recognition of human and vehicle). Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Free IP monitoring software available
|
| Mudel | IPC-HDW3549H-ASPV0280BS4 |
| Kaamera disain | Eyeball |
| Võrgukaamera tüüp | HDTV/Megapixel/Outdoor |
| Efektiivseid megapiksleid | 5 Mega Pixel |
| Objektiivi fokaalvahemik | 2.8 mm |
| IR valgustus | Yes |
| Sensori suurus | 1/2.7" |
| Mikrofoon | Built-in |
| Objektiivikinnitus | M12 |
| Minimaalne valgustus | 0.003 Lux |
| Efektiivsed pikslid | 2960 (H) × 1668 (V) |
| Elektrooniline säriaeg | Auto/Manual 1/3 s–1/100,000 s |
| RJ45 | 1 |
| Alarmi sisendpordid | 1 |
| Alarmi väljundpordid | 1 |
| Audio-Out sisend | 1 |
| Audio-in sisend | 1 |
| Toetab kaardi mahtusid kuni | 256GB |
| Toitevalikud | 12V/PoE |
| Toiteadapteri/ploki nõue | PoE / 12VDC power, 7.3W max |
| Energiatarbimine | 7.3 Watts |
| Keskkond | Outdoor |
| Töötemperatuuri ulatus | -40°C~+60°C |
| Värvus | White |
| Kaal | 0.745 kg |
| Brutokaal | 0.94 kg |
| Üksuse kasti laius | 0.15 |
| Üksuse kasti pikkus | 0.15 |
| Üksuse kasti kõrgus | 0.14 |
| Täiskirjeldus | Type HDTV/Megapixel/Outdoor|Pixel Resolution 5 Mega Pixel|Focal Length 2.8 mm|IR Illumination|Sensor size 1/2.7"|Mikrofon Built-in|Lens Mount M12|Min. Illumination 0.003 Lux|Effective pixels 2960 (H) × 1668 (V)|Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s|1xAudio-In|1xAudio-Out|1xRJ45|1xAlarm In|1xAlarm Out|Supports card capacities up to 256GB|Power options PoE/12V|Power supply requirements PoE / 12VDC power, 7.3W max|Environment Outdoor|Operating temperature range -40°C~+60°C|Colour White |
| Kategooria kood | FNC |
