Type HDTV/Megapixel/Outdoor | Pixel Resolution 5 Mega Pixel | Focal Length 2.8 mm | IR Illumination | Sensor size 1/2.7” | Microphone Built-in | Lens Mount M12 | Min. Illumination 0.0009 Lux | Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s | 1xAudio-In | 1xAudio-Out | 1xRJ45 | 1xAlarm In | 1xAlarm Out | Supports card capacities up to 256GB | Power options PoE/12V | Power supply requirements PoE / 12VDC power, 6.8W max | Environment Outdoor | Operating temperature range -40°C~+60°C | Colour Black | Dimensions 99.1 mm × Φ121.9 mm
Kirjeldus | 1/2.7” 5Megapixel progressive CMOS, 2960 × 1668 @ 30FPS max
Minimum illumination: 0.0009 lux @F1.6 (Color, 30 IRE); 0.0005 lux @F1.6 (B/W, 30 IRE); 0 lux (Illuminator on)
True Day/Night (ICR), BLC/HLC/True WDR 120 dB/3D DNR
2.8 mm fixed lens (111° HFOV)
Up to 50 meters IR LED Illumination
H.265; H.264; H.264H; H.264B; MJPEG encoding, ONVIF (Profile S/Profile G/Profile T); CGI
Built-in MIC, 1/1 Audio I/O, 1/1 Alarm I/O
Micro SD card up to 256GB supported
Metal core, IP67, -40°C~+60°C, PoE / 12VDC power, 6.8W max
With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, people counting, etc.
Free IP monitoring software available
|
Tootja lehekülg | www.dahuasecurity.com/products/All-Products/Network-Cameras/WizMind-S-Series/5MP/IPC-HDW5541TM-ASE=S3 |
Mudel | IPC-HDW5541TM-ASE-0280B-S3-B |
Kaamera disain | Eyeball |
Võrgukaamera tüüp | HDTV/Megapixel/Outdoor |
Efektiivseid megapiksleid | 5 Mega Pixel |
Objektiivi fokaalvahemik | 2.8 mm |
IR valgustus | Yes |
Sensori suurus | 1/2.7” |
Mikrofoon | Built-in |
Objektiivikinnitus | M12 |
Minimaalne valgustus | 0.0009 Lux |
Elektrooniline säriaeg | Auto/Manual 1/3 s–1/100,000 s |
Alarmi sisendpordid | 1 |
Alarmi väljundpordid | 1 |
Audio-in sisend | 1 |
Audio-Out sisend | 1 |
RJ45 | 1 |
Toetab kaardi mahtusid kuni | 256GB |
Toitevalikud | 12V/PoE |
Toiteadapteri/ploki nõue | PoE / 12VDC power, 6.8W max |
Energiatarbimine | 6.8 Watts |
Keskkond | Outdoor |
Töötemperatuuri ulatus | -40°C~+60°C |
Värvus | Black |
Mõõtmed (füüsilised parameetrid) | 99.1 mm × Φ121.9 mm |
Kaal | 0.5 kg |
Brutokaal | 0.718 kg |
Üksuse kasti laius | 0.14 |
Üksuse kasti pikkus | 0.15 |
Üksuse kasti kõrgus | 0.135 |
Täiskirjeldus | Type HDTV/Megapixel/Outdoor|Pixel Resolution 5 Mega Pixel|Focal Length 2.8 mm|IR Illumination|Sensor size 1/2.7”|Mikrofon Built-in|Lens Mount M12|Min. Illumination 0.0009 Lux|Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s|1xAudio-In|1xAudio-Out|1xRJ45|1xAlarm In|1xAlarm Out|Supports card capacities up to 256GB|Power options PoE/12V|Power supply requirements PoE / 12VDC power, 6.8W max|Environment Outdoor|Operating temperature range -40°C~+60°C|Colour Black|Dimensions 99.1 mm × Φ121.9 mm |
Kategooria kood | FNC |
